Globe valve · ASTM A216 WCB · API 623 · ASME B16.10 · UAE stock
A cast steel globe valve built to API 623, with bolted bonnet, outside screw and yoke, rising stem and RF flanges. The plug-type disc moves perpendicular to the seat, giving reliable throttling and tight shut-off on steam, oil and water.
Checked stock, standard-compliant
Full sizes, ratings & materials
Ready inventory, UAE & GCC delivery
Project quantities at best price
An API globe valve is a steel globe valve built to API 623, the American Petroleum Institute standard for flanged and butt-weld globe valves. Flow passes through an S-shaped body and up through a seat ring, where a disc moves straight down to close it. Because the disc travel is proportional to flow, the valve can throttle steadily without damaging the seat, unlike a gate or ball valve. Trim is usually 13% chromium stainless with hard-faced seats.
Hamza Fasteners supplies API globe valves in WCB carbon steel from 2" to 12" in Class 150 and 300, with face-to-face to ASME B16.10 and flanges to ASME B16.5. They are used on steam headers, boiler feed, fuel oil heating, bypass lines around control valves and cooling water regulation. Larger sizes can be supplied with gear operators. Send your datasheet to our Dubai office for an offer.
Reference data for API Globe Valve. Confirm exact size, rating and material for your order with our team.
This datasheet shows representative sizes for reference only. API Globe Valve is supplied in the full range of sizes, ratings and materials — not a single option. Tell us what you need and we will confirm exact availability, specification and price.
| Valve Size | Nominal DN | Face-to-Face (in) | Face-to-Face (mm) |
|---|---|---|---|
| 2" | DN50 | 8.00 | 203 |
| 2-1/2" | DN65 | 8.50 | 216 |
| 3" | DN80 | 9.50 | 241 |
| 4" | DN100 | 11.50 | 292 |
| 6" | DN150 | 16.00 | 406 |
| 8" | DN200 | 19.50 | 495 |
| 10" | DN250 | 24.50 | 622 |
| 12" | DN300 | 27.50 | 699 |
| Product Type | Globe valve, OS&Y, bolted bonnet |
|---|---|
| Body Material | ASTM A216 WCB |
| Trim | 13% Cr, Stellite faced on request |
| Design Standard | API 623, ASME B16.34 |
| Pressure Class | ASME Class 150 and 300 |
| End Connection | RF flanged to ASME B16.5 |
| Size Range | 2" to 12" |
Header and bypass throttling
Feed water regulation
Heating and transfer lines
Cooling water regulation
Control valve bypasses
Engine room services
Stocked in Deira, Dubai and delivered fast across the region. Wherever you are building, we supply in stock and project quantities.
Hamza Fasteners is a trusted API Globe Valve supplier in Dubai and across the United Arab Emirates — Abu Dhabi, Sharjah and Ajman — with regular export supply to Saudi Arabia (Riyadh, Jeddah, Dammam), Qatar (Doha), Kuwait City, Oman (Muscat) and key East and West African markets including Tanzania (Dar es Salaam), Kenya (Nairobi and Mombasa), Nigeria (Lagos) and Ethiopia (Addis Ababa). Looking for a "API Globe Valve supplier near me" or the best price in your city? Send us your requirement for a same-day quote.
Share the size, material, rating and quantity. We will confirm stock and send a quick quote with the datasheet and best price.
