Equal cross · carbon steel A234 WPB · ASME B16.9 · Dubai stock
A four-way carbon steel buttweld cross with equal bevelled ends, used to take two opposite branches off a welded header at one point. Made to ASME B16.9 in SCH 40 and SCH 80.
Checked stock, standard-compliant
Full sizes, ratings & materials
Ready inventory, UAE & GCC delivery
Project quantities at best price
A buttweld cross has four equal ends at right angles, all bevelled for butt welding. It brings two branches off a main line at the same point, which saves space on headers and manifolds compared with two tees. Like other B16.9 fittings it is formed with reinforcement at the junction and rated the same as straight pipe of its schedule and material.
We supply equal crosses from 1" to 8" in SCH 40 and SCH 80. They are used on fire and sprinkler ring mains, distribution manifolds, cooling water headers and fabricated structures. Because four welds meet in one fitting, careful fit-up and weld sequence matter. Each end is bevelled at 37.5° and the body is seamless for even wall. Ask Hamza Fasteners in Dubai for stock and prices.
Reference data for Buttweld Cross. Confirm exact size, rating and material for your order with our team.
This datasheet shows representative sizes for reference only. Buttweld Cross is supplied in the full range of sizes, ratings and materials — not a single option. Tell us what you need and we will confirm exact availability, specification and price.
| Size | OD (mm) | Centre to End C (mm) | End to End 2C (mm) |
|---|---|---|---|
| 1" | 33.4 | 38 | 76 |
| 1-1/4" | 42.2 | 48 | 96 |
| 1-1/2" | 48.3 | 57 | 114 |
| 2" | 60.3 | 64 | 128 |
| 2-1/2" | 73.0 | 76 | 152 |
| 3" | 88.9 | 86 | 172 |
| 4" | 114.3 | 105 | 210 |
| 6" | 168.3 | 143 | 286 |
| 8" | 219.1 | 178 | 356 |
| Product Type | Equal cross, butt weld |
|---|---|
| Material | ASTM A234 WPB carbon steel |
| Standard | ASME B16.9 |
| Schedule | SCH 40, SCH 80 |
| End Prep | 37.5° bevel, four ends |
| Size Range | 1" – 8" |
Four-way junctions
Distribution headers
Plant headers
Pump station pipework
Utility headers
Fabricated frames
Stocked in Deira, Dubai and delivered fast across the region. Wherever you are building, we supply in stock and project quantities.
Hamza Fasteners is a trusted Buttweld Cross supplier in Dubai and across the United Arab Emirates — Abu Dhabi, Sharjah and Ajman — with regular export supply to Saudi Arabia (Riyadh, Jeddah, Dammam), Qatar (Doha), Kuwait City, Oman (Muscat) and key East and West African markets including Tanzania (Dar es Salaam), Kenya (Nairobi and Mombasa), Nigeria (Lagos) and Ethiopia (Addis Ababa). Looking for a "Buttweld Cross supplier near me" or the best price in your city? Send us your requirement for a same-day quote.
Share the size, material, rating and quantity. We will confirm stock and send a quick quote with the datasheet and best price.
