Reducing tee · galvanised malleable iron · EN 10242 · UAE stock
A tee with a full-size run and a smaller branch outlet, so a lateral can be taken off a main without a separate reducing bush. Fewer joints mean fewer leak paths and a cleaner installation.
Checked stock, standard-compliant
Full sizes, ratings & materials
Ready inventory, UAE & GCC delivery
Project quantities at best price
A G.I. reducing tee keeps the run at main line size while the branch is reduced, for example 1 inch by 1 inch by 1/2 inch. Ordering is run x run x branch. It replaces an equal tee plus reducing bush, removing a threaded joint and the step that a bush creates in the waterway. Cast in malleable iron and hot-dip galvanised, it suits water, air and low pressure gas distribution.
Hamza Fasteners stocks galvanised reducing tees in common combinations from 3/4 x 1/2 inch to 4 x 2 inch, threaded BSPT with NPT on request. Typical uses are feeding fixture branches from a riser, sprinkler drops from cross mains and air drops from a ring main. Send the exact run and branch sizes to our Deira, Dubai team.
Reference data for G.I. Reducing Tee. Confirm exact size, rating and material for your order with our team.
This datasheet shows representative sizes for reference only. G.I. Reducing Tee is supplied in the full range of sizes, ratings and materials — not a single option. Tell us what you need and we will confirm exact availability, specification and price.
| Size (Run x Branch) | Run Pipe OD (mm) | Branch Pipe OD (mm) | Run TPI | Branch TPI |
|---|---|---|---|---|
| 3/4" x 1/2" | 26.9 | 21.3 | 14 | 14 |
| 1" x 1/2" | 33.7 | 21.3 | 11 | 14 |
| 1" x 3/4" | 33.7 | 26.9 | 11 | 14 |
| 1-1/4" x 1" | 42.4 | 33.7 | 11 | 11 |
| 1-1/2" x 1" | 48.3 | 33.7 | 11 | 11 |
| 2" x 1" | 60.3 | 33.7 | 11 | 11 |
| 2" x 1-1/2" | 60.3 | 48.3 | 11 | 11 |
| 3" x 2" | 88.9 | 60.3 | 11 | 11 |
| 4" x 2" | 114.3 | 60.3 | 11 | 11 |
| Product Type | Reducing tee, reduced branch |
|---|---|
| Material | Malleable cast iron |
| Coating | Hot-dip galvanised |
| Standard | EN 10242 / ASME B16.3 |
| Thread | BSPT or NPT, female |
| Size Range | 3/4" x 1/2" to 4" x 2" |
Riser to basin feeds
Cross main to branch
Ring main to tool point
Main to lateral
Equipment take-offs
Service branches
Stocked in Deira, Dubai and delivered fast across the region. Wherever you are building, we supply in stock and project quantities.
Hamza Fasteners is a trusted G.I. Reducing Tee supplier in Dubai and across the United Arab Emirates — Abu Dhabi, Sharjah and Ajman — with regular export supply to Saudi Arabia (Riyadh, Jeddah, Dammam), Qatar (Doha), Kuwait City, Oman (Muscat) and key East and West African markets including Tanzania (Dar es Salaam), Kenya (Nairobi and Mombasa), Nigeria (Lagos) and Ethiopia (Addis Ababa). Looking for a "G.I. Reducing Tee supplier near me" or the best price in your city? Send us your requirement for a same-day quote.
Share the size, material, rating and quantity. We will confirm stock and send a quick quote with the datasheet and best price.
