Elastomer flange gaskets · EPDM, NBR, neoprene · ASME B16.21 · UAE stock
Rubber flange gaskets seal under very low bolt load, which makes them the usual choice for water, drainage and HVAC flanges, plastic and cast iron flanges, and pump connections.
Checked stock, standard-compliant
Full sizes, ratings & materials
Ready inventory, UAE & GCC delivery
Project quantities at best price
An elastomer gasket fills flange surface imperfections with very little compression, so it seals well on flat-face cast iron, ductile iron, PVC and HDPE flange adaptors where high bolt torque would crack or distort the flange. Rubber is limited in temperature and pressure compared with fibre or metal gaskets, and it can extrude if over-tightened, so it is best kept to water and low-pressure utility service.
Hamza Fasteners supplies EPDM for potable water, chilled water and hot water, NBR for oils and fuels, and neoprene (CR) for general weather-resistant duty. Gaskets are available full face or ring, 1/2" to 24", for ASME Class 150 and PN10/16 flanges. Typical buyers are MEP contractors and water utilities. Request a quote from Dubai with sizes and medium.
Reference data for Rubber Flange Gasket. Confirm exact size, rating and material for your order with our team.
This datasheet shows representative sizes for reference only. Rubber Flange Gasket is supplied in the full range of sizes, ratings and materials — not a single option. Tell us what you need and we will confirm exact availability, specification and price.
| NPS | ID (in) | OD (in) | Bolt Circle (in) | Holes x Dia (in) |
|---|---|---|---|---|
| 1/2" | 0.84 | 3.50 | 2.38 | 4 x 0.62 |
| 3/4" | 1.06 | 3.88 | 2.75 | 4 x 0.62 |
| 1" | 1.31 | 4.25 | 3.12 | 4 x 0.62 |
| 1-1/2" | 1.91 | 5.00 | 3.88 | 4 x 0.62 |
| 2" | 2.38 | 6.00 | 4.75 | 4 x 0.75 |
| 3" | 3.50 | 7.50 | 6.00 | 4 x 0.75 |
| 4" | 4.50 | 9.00 | 7.50 | 8 x 0.75 |
| 6" | 6.62 | 11.00 | 9.50 | 8 x 0.88 |
| 8" | 8.62 | 13.50 | 11.75 | 8 x 0.88 |
| Product Type | Elastomer flange gasket |
|---|---|
| Material | EPDM, NBR, Neoprene (CR), SBR |
| Standard | ASME B16.21; EN 1514-1 |
| Flange Class | ASME 150; PN10 / PN16 |
| Style | Full face or ring |
| Hardness | Typically 60 – 70 Shore A |
| Size Range | 1/2" – 24" |
EPDM gaskets
HVAC flanges
Pump & valve flanges
Flanged valves
PVC & HDPE adaptors
NBR gaskets
Stocked in Deira, Dubai and delivered fast across the region. Wherever you are building, we supply in stock and project quantities.
Hamza Fasteners is a trusted Rubber Flange Gasket supplier in Dubai and across the United Arab Emirates — Abu Dhabi, Sharjah and Ajman — with regular export supply to Saudi Arabia (Riyadh, Jeddah, Dammam), Qatar (Doha), Kuwait City, Oman (Muscat) and key East and West African markets including Tanzania (Dar es Salaam), Kenya (Nairobi and Mombasa), Nigeria (Lagos) and Ethiopia (Addis Ababa). Looking for a "Rubber Flange Gasket supplier near me" or the best price in your city? Send us your requirement for a same-day quote.
Share the size, material, rating and quantity. We will confirm stock and send a quick quote with the datasheet and best price.
