Bellow seal globe valve · cast steel · flanged EN 1092-1 · UAE stock
A globe valve with a stainless steel bellows welded between stem and bonnet, giving a hermetic stem seal with a back-up gland. It is the standard choice for steam, thermal oil and toxic or costly media where gland leakage cannot be tolerated.
Checked stock, standard-compliant
Full sizes, ratings & materials
Ready inventory, UAE & GCC delivery
Project quantities at best price
A globe valve with bellow seal replaces the usual packed gland as the main stem seal with a multi-ply stainless steel bellows. One end of the bellows is welded to the stem and the other to the bonnet, so the stem can rise and fall while the process fluid stays completely sealed inside. A conventional gland sits above as a back-up. This removes the steady gland weeping, energy loss and maintenance that packed valves show on hot steam and thermal oil lines.
Hamza Fasteners supplies bellow seal globe valves from DN15 to DN200 in cast steel, PN16, PN25 and PN40, with flanges to EN 1092-1 and face-to-face to EN 558 Series 1. Typical users are laundries, food factories, hotels with central steam, thermal oil heaters, asphalt plants and chemical plants handling hazardous media. Send the media, temperature and pressure to our Dubai team so we can confirm the right rating.
Reference data for Bellow Seal Globe Valve. Confirm exact size, rating and material for your order with our team.
This datasheet shows representative sizes for reference only. Bellow Seal Globe Valve is supplied in the full range of sizes, ratings and materials — not a single option. Tell us what you need and we will confirm exact availability, specification and price.
| Nominal DN | Approx. NPS | Face-to-Face (mm) |
|---|---|---|
| DN15 | 1/2" | 130 |
| DN20 | 3/4" | 150 |
| DN25 | 1" | 160 |
| DN32 | 1-1/4" | 180 |
| DN40 | 1-1/2" | 200 |
| DN50 | 2" | 230 |
| DN65 | 2-1/2" | 290 |
| DN80 | 3" | 310 |
| DN100 | 4" | 350 |
| DN150 | 6" | 480 |
| Product Type | Bellows sealed globe valve |
|---|---|
| Body Material | Cast steel GP240GH (1.0619) or WCB |
| Bellows | Multi-ply stainless steel |
| Stem Seal | Bellows plus back-up packed gland |
| Pressure Rating | PN16, PN25, PN40 |
| End Connection | Flanged EN 1092-1 |
| Size Range | DN15 to DN200 |
Header and branch isolation
Heater and consumer valves
Central steam plant
Cooking and process steam
Toxic or volatile media
Hot oil jacketing lines
Stocked in Deira, Dubai and delivered fast across the region. Wherever you are building, we supply in stock and project quantities.
Hamza Fasteners is a trusted Bellow Seal Globe Valve supplier in Dubai and across the United Arab Emirates — Abu Dhabi, Sharjah and Ajman — with regular export supply to Saudi Arabia (Riyadh, Jeddah, Dammam), Qatar (Doha), Kuwait City, Oman (Muscat) and key East and West African markets including Tanzania (Dar es Salaam), Kenya (Nairobi and Mombasa), Nigeria (Lagos) and Ethiopia (Addis Ababa). Looking for a "Bellow Seal Globe Valve supplier near me" or the best price in your city? Send us your requirement for a same-day quote.
Share the size, material, rating and quantity. We will confirm stock and send a quick quote with the datasheet and best price.
