Ring type joint · solid metal ring · ASME B16.20 / API 6A · UAE stock
RTJ gaskets are solid metal rings that seat in matching grooves in ring-type-joint flanges. They are used for high-pressure oil and gas service where soft gaskets would blow out.
Checked stock, standard-compliant
Full sizes, ratings & materials
Ready inventory, UAE & GCC delivery
Project quantities at best price
A ring type joint gasket is a precision-machined metal ring. When the flanges are bolted up, the ring is forced into trapezoidal grooves in both faces and deforms plastically, creating a metal-to-metal line seal. To work, the ring must be softer than the flange groove, so material and hardness are selected against the flange: soft iron or low carbon steel for carbon steel flanges, stainless for stainless flanges.
Hamza Fasteners supplies R-series oval and octagonal rings for ASME B16.5 RTJ flanges, plus RX and BX rings for API 6A wellhead equipment. Typical users are oilfield service companies, refineries and pipeline contractors. Each ring is marked with its number and material. Send ring numbers, or flange size and class, to our Dubai office for a quote.
Reference data for RTJ Ring Joint Gasket. Confirm exact size, rating and material for your order with our team.
This datasheet shows representative sizes for reference only. RTJ Ring Joint Gasket is supplied in the full range of sizes, ratings and materials — not a single option. Tell us what you need and we will confirm exact availability, specification and price.
| NPS | Class 150 | Class 300 / 600 |
|---|---|---|
| 1" | R15 | R16 |
| 1-1/2" | R19 | R20 |
| 2" | R22 | R23 |
| 3" | R29 | R31 |
| 4" | R36 | R37 |
| 6" | R43 | R45 |
| 8" | R48 | R49 |
| 10" | R52 | R53 |
| 12" | R56 | R57 |
| Product Type | Ring type joint gasket |
|---|---|
| Material | Soft iron, low carbon steel, 4-6% Cr, SS 304 / 316 |
| Standard | ASME B16.20, API 6A |
| Profile | R oval, R octagonal, RX, BX |
| Max Hardness | Soft iron 90 HB; LCS 120 HB; SS 316 160 HB |
| Finish | Machined, corrosion-protected |
API 6A RX / BX rings
High-pressure flanges
Hydrogen & HP lines
Topside manifolds
Compressor piping
HP steam flanges
Stocked in Deira, Dubai and delivered fast across the region. Wherever you are building, we supply in stock and project quantities.
Hamza Fasteners is a trusted RTJ Ring Joint Gasket supplier in Dubai and across the United Arab Emirates — Abu Dhabi, Sharjah and Ajman — with regular export supply to Saudi Arabia (Riyadh, Jeddah, Dammam), Qatar (Doha), Kuwait City, Oman (Muscat) and key East and West African markets including Tanzania (Dar es Salaam), Kenya (Nairobi and Mombasa), Nigeria (Lagos) and Ethiopia (Addis Ababa). Looking for a "RTJ Ring Joint Gasket supplier near me" or the best price in your city? Send us your requirement for a same-day quote.
Share the size, material, rating and quantity. We will confirm stock and send a quick quote with the datasheet and best price.
