Pipe plug · galvanised malleable iron · EN 10242 · UAE stock
A solid male-threaded fitting that screws into a female outlet to seal it. Used to blank spare tee branches, drain points and test openings, and to close fittings during pressure testing.
Checked stock, standard-compliant
Full sizes, ratings & materials
Ready inventory, UAE & GCC delivery
Project quantities at best price
A G.I. plug is a short solid fitting with a taper male thread and a square or hexagon head. It screws into a female-threaded outlet such as a tee branch, socket, elbow or valve body to close it. Because the male taper wedges into the female thread, a plug with PTFE tape or sealant gives a pressure-tight seal that can be removed later to extend the line or drain it. It is the male counterpart of a cap.
Hamza Fasteners supplies galvanised plugs from 1/4 inch to 4 inch in BSPT and NPT threads. Contractors in Dubai use them to blank tee outlets during first fix, close drain and vent points, and seal openings for hydrostatic testing. Send sizes and thread type to our Deira counter for a price. Brass and steel plugs are also available for non-galvanised systems.
Reference data for G.I. Plug. Confirm exact size, rating and material for your order with our team.
This datasheet shows representative sizes for reference only. G.I. Plug is supplied in the full range of sizes, ratings and materials — not a single option. Tell us what you need and we will confirm exact availability, specification and price.
| Size | Thread | Major Dia (mm) | BSP TPI | NPT TPI |
|---|---|---|---|---|
| 1/4" | R 1/4 | 13.157 | 19 | 18 |
| 3/8" | R 3/8 | 16.662 | 19 | 18 |
| 1/2" | R 1/2 | 20.955 | 14 | 14 |
| 3/4" | R 3/4 | 26.441 | 14 | 14 |
| 1" | R 1 | 33.249 | 11 | 11.5 |
| 1-1/2" | R 1-1/2 | 47.803 | 11 | 11.5 |
| 2" | R 2 | 59.614 | 11 | 11.5 |
| 3" | R 3 | 87.884 | 11 | 8 |
| 4" | R 4 | 113.030 | 11 | 8 |
| Product Type | Pipe plug, male threaded |
|---|---|
| Material | Malleable cast iron |
| Coating | Hot-dip galvanised |
| Standard | EN 10242 / ASME B16.3 style |
| Thread | BSPT (R) or NPT |
| Head | Square or beaded hex |
| Size Range | 1/4" to 4" |
Closing open ports
Low point drains
Future connections
Test and drain tees
Spare tank ports
First fix blanking
Stocked in Deira, Dubai and delivered fast across the region. Wherever you are building, we supply in stock and project quantities.
Hamza Fasteners is a trusted G.I. Plug supplier in Dubai and across the United Arab Emirates — Abu Dhabi, Sharjah and Ajman — with regular export supply to Saudi Arabia (Riyadh, Jeddah, Dammam), Qatar (Doha), Kuwait City, Oman (Muscat) and key East and West African markets including Tanzania (Dar es Salaam), Kenya (Nairobi and Mombasa), Nigeria (Lagos) and Ethiopia (Addis Ababa). Looking for a "G.I. Plug supplier near me" or the best price in your city? Send us your requirement for a same-day quote.
Share the size, material, rating and quantity. We will confirm stock and send a quick quote with the datasheet and best price.
