Gasket sheet · expanded graphite, plain or reinforced · cut gaskets · UAE stock
Flexible graphite sheet is exfoliated graphite rolled into a soft, conformable jointing material. It handles high temperatures, does not age or creep like rubber-bound sheet, and resists almost all chemicals except strong oxidisers.
Checked stock, standard-compliant
Full sizes, ratings & materials
Ready inventory, UAE & GCC delivery
Project quantities at best price
Graphite gasket sheet is made by expanding natural graphite flakes and rolling them into a dense, flexible sheet with high carbon content and no binder to break down. It conforms to flange damage, seals with modest bolt load and keeps its properties over a wide temperature span. In air, oxidation limits continuous service to roughly 450 °C; in steam or inert conditions it can go higher. Plain sheet is fragile, so SS 316 tanged or flat foil inserts are added for handling and blow-out resistance.
Hamza Fasteners supplies graphite sheet in plain and reinforced grades, 0.5 to 3 mm, and cuts ring or full-face gaskets to ASME or PN sizes. It suits steam, thermal oil, heat exchangers and hydrocarbon service, and is a common upgrade where rubber-bound fibre gaskets harden and leak after repeated heat cycles. Tanged sheet should be cut with snips or a die, not a knife, and handled with gloves. Send sheet size or gasket list to our Dubai team.
Reference data for Graphite Gasket Sheet. Confirm exact size, rating and material for your order with our team.
This datasheet shows representative sizes for reference only. Graphite Gasket Sheet is supplied in the full range of sizes, ratings and materials — not a single option. Tell us what you need and we will confirm exact availability, specification and price.
| Grade | Construction | Typical Thickness | Best For |
|---|---|---|---|
| Plain | Homogeneous flexible graphite | 0.5 – 3.0 mm | Low-pressure, cut packing, die-formed rings |
| Tanged insert | Graphite laminated on SS 316 tanged sheet | 1.0 – 3.0 mm | Steam, high pressure, rough flanges |
| Flat foil insert | Graphite on SS 316 flat foil | 1.0 – 3.0 mm | Easier cutting, moderate pressure |
| Inhibited grade | Graphite with oxidation inhibitor | Per base grade | Higher air temperatures |
| Cut gaskets | Ring or full face from any grade | To order | ASME B16.21 / EN 1514-1 sizes |
| Product Type | Flexible graphite gasket sheet |
|---|---|
| Material | Expanded graphite, high carbon content |
| Insert | None, SS 316 tanged or flat foil |
| Thickness | 0.5 – 3.0 mm |
| Temperature | Up to approx. 450 °C in air (grade dependent) |
| Supply | Full sheet or cut to ASME / PN sizes |
Boiler and header flanges
Heater circuits
Shell and channel joints
Hydrocarbon flanges
Turbine auxiliaries
Engine & generator
Stocked in Deira, Dubai and delivered fast across the region. Wherever you are building, we supply in stock and project quantities.
Hamza Fasteners is a trusted Graphite Gasket Sheet supplier in Dubai and across the United Arab Emirates — Abu Dhabi, Sharjah and Ajman — with regular export supply to Saudi Arabia (Riyadh, Jeddah, Dammam), Qatar (Doha), Kuwait City, Oman (Muscat) and key East and West African markets including Tanzania (Dar es Salaam), Kenya (Nairobi and Mombasa), Nigeria (Lagos) and Ethiopia (Addis Ababa). Looking for a "Graphite Gasket Sheet supplier near me" or the best price in your city? Send us your requirement for a same-day quote.
Share the size, material, rating and quantity. We will confirm stock and send a quick quote with the datasheet and best price.
